xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
576
Parameters
mac_source - Indicates that the switch should examine the MAC source address.
mac_destination - Indicates that the switch should examine the MAC destination address.
mac_source_dest - Indicates that the switch should examine the MAC source and destination
address.
ip_source - Indicate that the switch should examine the IP source address.
ip_destination - Indicate that the switch should examine the IP destination address.
ip_source_dest - Indicate that the switch should examine the IP source and destination address.
l4_src_port - Indicate that the switch should examine the Layer 4 source port.
l4_dest_port - Indicate that the switch should examine the Layer 4 destination port.
l4_src_dest_port - Indicate that the switch should examine the Layer 4 source and destination port.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the link aggregation algorithm to mac-source-dest:
DGS-3420-28SC:admin#config link_aggregation algorithm mac_source_dest
Command: config link_aggregation algorithm mac_source_dest
Success.
DGS-3420-28SC:admin#
50-5 show link_aggregation
Description
This command is used to display the current link aggregation configuration of the switch.
Format
show link_aggregation {group_id <value 1-32> | algorithm}
Parameters
group_id - (Optional) Specify the group ID. The group number identifies each of the groups.
<value 1-32> - The switch allows up to 32 link aggregation groups to be configured.
algorithm - (Optional) Specify the display of link aggregation by the algorithm in use by that group.
Note: If no parameter is specified, the system will display all the link aggregation information.
Restrictions
None.
