xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
587
Example
To change the SNMP notification state of ports 1 to 5 to enable:
DGS-3420-28SC:admin#config lldp ports 1-5 notification enable
Command: config lldp ports 1-5 notification enable
Success.
To configure the mode of ports 1 to 5 to transmit and receive:
DGS-3420-28SC:admin#config lldp ports 1-5 admin_status tx_and_rx
Command: config lldp ports 1-5 admin_status tx_and_rx
Success.
To enable ports 1 to 5 to manage address entries:
DGS-3420-28SC:admin#config lldp ports 1-5 mgt_addr ipv4 192.168.254.10 enable
Command: config lldp ports 1-5 mgt_addr ipv4 192.168.254.10 enable
Success.
To exclude the system name TLV from the outbound LLDP advertisements for all ports:
DGS-3420-28SC:admin#config lldp ports all basic_tlvs system_name enable
Command: config lldp ports all basic_tlvs system_name enable
Success.
To exclude the VLAN name TLV from the outbound LLDP advertisements for all ports:
DGS-3420-28SC:admin#config lldp ports all dot1_tlv_pvid enable
Command: config lldp ports all dot1_tlv_pvid enable
Success.
To exclude the port and protocol VLAN ID TLV from the outbound LLDP advertisements for all ports:
