xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

609

Example

To enable the log state for LBD:

DGS-3420-28SC:admin# config loopdetect log state enable

Command: config loopdetect log state enable

Success.

DGS-3420-28SC:admin#
