D-Link xStack DGS-3420 Series User Manual

xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
622
Command: config mac_based_access_control method local
Success.
DGS-3420-28SC:admin#
55-5 config mac_based_access_control guest_vlan ports
Description
This command is used to put the specified port in guest VLAN mode. For those ports not contained in
the port list, they are in non-guest VLAN mode.For detailed information about the operation of guest
VLAN mode, please see the description for configuring the MAC-based access control port command.
Format
config mac_based_access_control guest_vlan ports <portlist>
Parameters
<portlist> - When a port is configured as gurest VLAN member port, this port will move to guest
VLAN if it’s MAC-based access control state is enable.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the MAC-based access control guest VLAN membership for port 1 to 8:
DGS-3420-28SC:admin# config mac_based_access_control guest_vlan ports 1-8
Command: config mac_based_access_control guest_vlan ports 1-8
Success.
DGS-3420-28SC:admin#
55-6 config mac_based_access_control ports
Description
This command is used to configure the MAC-based access control setting. When the MAC-based
access control function is enabled for a port, and the port is not a MAC-based access control guest
VLAN member, the user who is attached to this port will not be forwarded unless the user passes the
authentication. A user that does not pass the authentication will not be serviced by the switch. If the
user passes the authentication, the user will be able to forward traffic operated under the assigned
VLAN.
