xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

745

Parameters

None.

Restrictions

Only Administrator-level users can issue this command.

Example

To display the password recovery state:

DGS-3420-28SC:admin# show password_recovery

Command: show password_recovery

Running Configuration : Disabled

NV-RAM Configuration : Enabled

DGS-3420-28SC:admin#
