Daewoo Mega 500-V - Page 188

S0602170K
Page 83
Axle (ZF AP 420R)
6. Insert side gear and assemble inner plates
at the same time.
7. Insert the complete differential spider.
8. Install the second side gear.
NOTE: Pay attention to the radial
installation position of the
pressure ring.
9. Install the second pressure ring and insert
all drive pins.
NOTE: Pay attention to the radial
installation position of the
pressure ring.
Figure 175
Figure 176
Figure 177
Figure 178
