Daewoo Mega 500-V - Page 206

S0602170K
Page 101
Axle (ZF AP 420R)
3. Insert pre-assembled differential case half
in the axle carrier.
4. Make the two thrust washers adhere with
grease in the housing cover.
NOTE: Mount brass washer on top with
the lubricating groove facing
the side gear.
5. Lay housing cover over the differential
case.
NOTE: Pay attention to the installation
position (see Figure 229).
6. Fasten the housing cover using locking
screws.
NOTE: Only use locking screws one
time. Do not reuse them.
NOTE: See “Special Tools” on page 15.
Figure 227
Figure 228
Figure 229
Figure 230
