S0607080K
Page 48
Transmission and Torque Converter
(ZF 4WG-310)
2. 2. Separate hose lines from the
intermediate plate.
3. Loosen socket head screws and separate
intermediate plate and gaskets and
intermediate sheet from gearbox housing.
4. Mark installation position of the cable
harness to the valve block.
5. Loosen socket head screws.
6. Separate duct plate, gaskets and
intermediate sheet from the valve block.
7. Remove retaining clip.
Figure 43
Figure 44
Figure 45
Figure 46
