S0607080K
Page 58
Transmission and Torque Converter
(ZF 4WG-310)
H. Install 2 adjusting screws (M6).
I. Mount gasket (Figure 80).
J. Fasten complete valve block
uniformly with socket head screws (2
pieces M6 x 105 and 21 pieces M6 x
80 mm).
NOTE:
Torque limit 9.5 Nm (7 ft lb).
CAUTION!
Pay attention to the position of the
two socket head screws (M6 x 105),
see Allows.
Figure 80
Figure 81
