Daewoo Mega 500-V - Page 322

S0607080K
Page 71
Transmission and Torque Converter
(ZF 4WG-310)
5. Pull inner bearing race from the shaft
(Figure 129).
6. Press opposite inner bearing race from the
shaft.
NOTE: The separation of shaft and
gear is not possible (shrink fit).
MULTIDISK CLUTCH - K3/K4
1. Fasten clutch using clamping ring (S) on
the assembly car.
2. Pull roller bearing from plate carrier.
3. Separate spur gear K3 from plate carrier.
Figure 129
Figure 130
Figure 131
Figure 132
