S0203070K
Page 9
Specifications for Mega 500-V
Category Dimension
Overall Length (A) 9,320 mm (30’ 7")
Overall Width, without bucket (B) 3,190 mm (10’ 6")
Overall Height (C) 3,780 mm (12’ 5")
Bucket Width (D) 3,480 mm (11’ 5")
Wheel Base (E) 3,600 mm (11’ 10")
Tread (F) 2,420 mm (7’ 11")
Ground Clearance (G) 490 mm (1’ 7")
Dump Height, to tooth (H) 3,080 mm (10’ 1")
Dump Distance, to Bucket Edge (I) 1,380 mm (4’ 6")
Dump Height to Bucket Pivot 4,470 mm (14’ 8")
Bucket Angle, Raised (a) 47°
Bucket Angle (b), Lowered (at carry) 48°
Tire Size 29.5-25-22 PR(L3)
