Electrical System
Return to Master Table of Contents
The lighting system consists of the headlight, the position light, the turn signal light, the hazard light, the
stop light, the license plate light, the working light, the rotating beacon light (option) and the switches,
which are used to turn on the lights.
1. When the headlight switch (3) is in the first step, through the fuse box 1 (1) to the "2," "6" terminal of
headlight switch (3), the following lights will be "ON."
A. The front combination light (L)(12) and rear combination light (L) through the fuse box 2 (23).
B. The front combination light (R)(13) and rear combination light (R) through the fuse box 2 (23).
C. The illumination lights through the "9" terminal of all kind of rocker switches include the
headlight switch (3), the front working light switch (19), the rear working light (21) and the
hazard switch (6).
D. The license plate light (16).
2. When the headlight switch (3) is in the second step, the current flows through the fuse box 1 (1), to
the "2," "3" terminal of headlight switch (3) and to the "86," "85" terminal of headlight relay (8), and the
"30," "87" terminal of headlight relay (8) is connected. As a result, through the fuse box 1 (1) to the
"30," "87" terminal of headlight relay (8), the voltage is applied to the "56" terminal of combination
switch (R)(4).
A. At this time if the combination switch (4) is in the "0" position, the current flows to the "56b"
terminal and it allow the low light, which is in the headlight (L)(10) and the headlight (R)(11), to
be turned "ON."
B. Also if the combination switch (4) is in the "t" position, the current flows to the "56a" terminal and
it allow the high light, which is in the headlight (L)(10) and the headlight (R)(11), to be "ON." At
the same time the current flows to the "CN2-7" terminal of instrument panel (17) and the
headlight indicator L7 will be "ON,"
C. And if the combination switch (4) is in the "s" position, the current flows to the "56b" terminal and
it allows the low light, which is in the headlight (L)(10) and the headlight (R)(11), to be "ON."
At the same time another current flows from the fuse box 1 (1) to the "15/1," "56b" terminal of
combination switch (4) and the high light, which is in the headlight (L)(10) and the headlight
Reference
Number
Description
1 Fuse Box 1
2 Blinker Unit
3 Headlight Switch
4 Combination Switch
5 Shift Lever Switch
6 Hazard Switch
Stop Light Switch7
8 Headlight Relay
9 Reverse Relay
10 Headlight (L)
11 Headlight (R)
12 Front Combination Light (L)
13 Front Combination Light (R)
Rear Combination Light (L)14
15 Rear Combination Light (R)
License Plate Light16
17 Instrument Panel
18 Diode
19 Front Working Light Switch
20 Front Working Light
21 Rear Working Light Switch
22 Working Light Relay
23 Rear Working Light 1
24 Rear Working Light 2
25 Fuse Box 2
26 Starter Switch
27 Pilot Buzzer
28 Alarm Relay 1
29 Alarm Relay 2
