E-GENIUS

111

Field Name

Action/Definition

transmitting the code stop character:

 Disabled: The character is not selected;

 Lower Case: The character is transmitted in lower case;

 Upper Case: The character is transmitted in upper case.

Data Matrix Fast

Improve

Select the check box to enable the Data Matrix options available via the

table shown below.

Data Matrix

Options

The following options are available for Data Matrix codes:

Select the Data Matrix Fast Improve check box and the check box next to

the Data Matrix type codes required from the provided table.

Select All to select all of the Data Matrix codes listed.

Select All Square to select all of the Data Matrix square codes.

Select All Rectangle to select all of the Data Matrix rectangular codes.

Select Clear to clear the table of any selections.

Postal

Symbologies

Select a symbology from the drop-down list, and then define its parameters

including:

 Postal Direction: Select Omnidirectional, Horizontal, Vertical, or

Horizontal/ Vertical from the drop-down list.

 Postal Bar Distance: Enter the bar distance in the field provided.

 Postal Max Bar Count: Enter the maximum number of bars in the field

provided.

 Postal Min Bar Count: Enter the minimum number of bars in the field

provided.

Code Module

Size

Enter number of code modules in the field provided.

Maxicode

Enable n

Select the check box corresponding to the Maxicode(s) to enable.

3. When you have finished making changes, click Update to save or click Reset to revert to

the previously saved values.
