AV7000 LINEAR CAMERA REFERENCE MANUAL
116
4
1. Enter the appropriate information in the form as described below:
Field Name
Action/Definition
Minimum 1D
Code Height
Enter the minimum code height in the field provided (mm [in])
Code
Combination
Standard Multi Label has been selected.
No Read
Message
Select Disable No Read Message, Global No Read Message, or Local No
Read(s) Message from the drop-down list. The No Read condition occurs whenever
a code cannot be read or decoded.
 Disable No Read Message: The No Read Message is not transmitted.
 Global No Read Message: The No Read String will be sent if the barcode reader
is unable to decode one or more barcodes in the reading phase.
 Local No Read(s) Message: This option is useful when one or more codes are
not read in the reading phase or when more codes than the expected number set
by the configuration parameters are read.
If working in Standard Multi Label mode, this option activates the Code Label
Local No Read String and the Code Label Local Multiple Read String
parameters which allow setting a Local No Read String and a Local Multiple
string for each defined code symbology.
No Read String
(max. 128
chars)
Click to activate the Text Entry Tool and create a string to be displayed when
Global No Read Message is selected from the No Read Message drop-down list.
Click Submit to save your text to the origin window text field, or click Cancel to
return to origin window without transferring text.
Multiple Read
Message
Select Disable or Enable from the drop-down list. This string will be sent if, during
the reading phase, the barcode reader reads more than the number of the expected
barcodes set by the configuration parameters.
Multiple Read
String (max.
128 chars)
Click to activate the Text Entry Tool and create a string to be displayed in case of
Multiple Read Message. Click Submit to save your text to the origin window text
field, or click Cancel to return to origin window without transferring text.
This parameter is only available when Multiple Read Message is enabled and the
No Read Message selection is different from Local No Read(s) String. It is possible
to select either the ASCII or HEX value. If disabled, the barcode reader transmits
the first code read.
Partial Read Is
Treated As
Select No Read, Good Read, or Partial Read from the drop-down list.
A Partial Read is a condition when multiple barcodes are enabled, but not all
barcodes are read during a trigger cycle.
Multi-Filter Settings
Strip Filter
Select the check box to display the Strip Filter Settings options. This is a second
level filter that when enabled allows eliminating characters not managed by the host.
Strip All Non
Printable Chars
Select the check box to remove all non- printable ASCII characters from the code
(000-020 and 127).
