AV7000 LINEAR CAMERA REFERENCE MANUAL
146
4
Field Name
Action/Definition
Item Type
Displays the message type including various Code Related Item, String, or Global
Item messages.
Qualifier
Displays relevant qualifiers for the message item if needed.
Advanced Formatter n - Item List Buttons
Add
Click to add a new message item to the bottom of the list. The type of message added
is based on the Item Type selected in the Item n Definition section of the window (see
below).
Add before
Click to add a new message item above the currently selected message.
Add after
Click to add a new message item below the currently selected message.
Move up
Click to move the selected message item up one level in the list.
Move down
Click to move the selected message item down one level in the list.
Remove
Click to remove the selected message item.
Item n Definition
Item Type
Select String, Code Related, or Global from the drop-down list. Each selection reveals
a unique set of options.
Code
Related
Items
Select a code related item from those available in the drop-down list. This option is
available when Item Type > Code Related has been selected. The Code Related
items can be associated to a specific programmed code or group label depending on
the Code Combination selection.
Selections Include:
 Code: Barcode data
 Length: Number of characters in code
 Read Mask: In tracking mode - 32-bit mask indicating which barcode reader in the
network has read the code (when character <1> is present in the related position). In
On Line mode - 32-bit mask indicating the lowest unit number barcode reader in the
network that read the code (when character <1> is present in the related position).
 Total Read Count: Indicates how many times the code has been read by all
barcode readers present in the network during the same reading phase.
 Read Count (by device): Indicates the number of times the code has been read by
one specific barcode reader present in the network during the reading phase
(selectable among those present).
 X Position: X coordinate for the code that was read
 Y Position: Y coordinate for the code that was read
 Z Position: Z coordinate for the code that was read
 Code Identifier: Indicates type of code that was read
 Code Direction: Indicates if the code has been read either from either the start
character or the stop character.
 Code Distance: Indicates the distance from the scan head to the code that was
read.
 Decode Mode: Indicates if the barcode reader is configured for Linear or
Reconstruction (ACR) reading mode.
 Decode Scans Number: Indicates the minimum number of decoded scans referred
to the single characters in a code when the device is reading in Reconstruction
mode. This Item can be used as Code Quality Index
