E-GENIUS
147
4
Field Name
Action/Definition
 Average Code Position: Average position of the code in the scan line (Average of
Minimum and Maximum Code Position)
 Minimum Code Position: Minimum position of the code in the scan line (closest to
the left side/connector side of the barcode reader)
 Maximum Code Position: Maximum position of the code in the scan line (farthest
from the left side/connector side of the barcode reader)
 Ink Spread: Indicates the calculated Ink Spread value. This indicates the sharp or
blurry quality of the code
 Encoder Value: Indicates the encoder/tachometer pulse value from trigger to the
code being read
 Reading Persistence: Indicates how many times the laser beam has crossed the
complete code during the reading phase
NOTE: Code Direction, Code Distance, Decode Mode,
Decode Scans Number, Ink Spread, Laser Number, and
Reading Persistence are available only when the
associated code is read by the Master device.
Global Item
Select a package related item from those available in the drop-down list. This option is
available when Item Type > Global has been selected.
Selections Include:
 Total Read Mask: Indicates the complete reading mask related to all codes read
during the reading phase
 Total Read Count: Indicates the sum of all Code-related Total Reading Counts of
each code read during the reading phase
 Sequence Number: Indicates the sequential number assigned to the package
 Hours: Indicates hour the code was scanned
 Minute: Indicates minute the code was scanned
 Seconds: Indicates second the code was scanned
 Day: Indicates day of the month the code was scanned
 Month: Indicates month the code was scanned
 Year: Indicates year the code was scanned
 Protocol Index: Indicates the programmed protocol index string data
 Parcel Length: Indicates the approximate length of the package
 Parcel Width: Indicates the approximate width of the package
 Parcel Height: Indicates the approximate height of the package
 Parcel Volume: Indicates the approximate volume of the package
 Parcel Orientation Angle: Indicates the angle of the package
 Image Filename: Includes the filename of the image
Code
Definition
Number
Select a Code Definition Number from those available in the drop-down list. This
option is available when Item Type > Code Related has been selected.
Text String: Options
