E-GENIUS
Example message: 01-123456789000-450
Message #2 will be a serial message.
<STX>(string of six Xs [xxxxxx] followed by last 4 digits of the barcode),hh:mm:ss<ETX>
Example message: xxxxxx8900,12:59:59
NOTE: In this example the Barcode Settings Table is set
up to read code 1 as a code128 4-40 characters barcode,
code 2 is set up as a code39 10 character barcode, and
the Code Combination selection is set for Logical
Combination. The Logical Combination rule equals 1&2.
Local No Read(s) Message is selected for the No Read
Message.
Start by setting up serial and ethernet connections for three messages:
1. Navigate to Modify Settings | Global Settings | Communications | Transports. The
Transports window opens.
2. Select the Serial option button #1.
3. Select the Enable check box.
4. Select Advanced from the Data Output Protocol drop-down list.
5. Select an index number from the Advanced Formatter Index. In this example 2 is
selected.
6. Select the Socket option button #2 at the top of the Transports window.
