AV7000 LINEAR CAMERA REFERENCE MANUAL
8. Navigate to Diagnostics | Focus Setup. The Focus Setup window opens.
9. Select Constant from the Tachometer drop-down list.
10. Select Left or Right from the Connector Position drop-down list depending on which
side the DM3610 connectors are on when looking down stream.
LEFT RIGHT
Figure 99: Connector Position
11. Enter a value of 0 (zero) in the Left Offset, Right Offset, and Height Offset fields.
12. Click Update.
To Next Page
Loading...
