Delta DVP-15MC Series User Manual

Chapter 12 Troubleshooting
12-21
1
2
System error code
Explanation Correction
Hexadecimal
Decimal
1603 5635
Full buffer area for USB
communication
Contact local technicians if the problem still
exists after re-downloading the program.
3000 12288
The number of inputs or the
number of outputs is greater than
the limit 32.
Reset the number of input and output
variables in the self-defined POU and make
sure the number of input or output variables
does not exceed 32.
3001 12289
The capacity for one POU is more
than 65535 bytes.
Change the capacity of variables in a POU to
reduce the variable occupation in the memory.
3002 12290
The number of POUs is more
than 1000.
Reduce the number of POUs called by the
task and re-download the program.
3003 12291 The POU type is illegal.
Update the software
if the error still exists after
re-compiling and re-downloading the program
and repowering the product.
3004 12292
The types of parameters in the
program are illegal.
3005 12293
Variable’s offset address error in
the program
3006 12294
The data types of parameters are
illegal in the program.
3007 12295
The jump range in a program is
illegal.
3008 12296
Program memory allocation
alignment is incorrect.
3009 12297
Virtual axis encoder memory
alignment is incorrect.
300A 12298
The Bit accessed exceeds the
range. (Only Bit0~Bit7 can be
accessed.)
Update the software if the error still exists after
re-compiling and re-downloading the program
and repowering the product.
300B 12299
It is detected that data types are
illegal in the program.
Update the software if the error still exists after
re-compiling and re-downloading the program
and repowering the product.
300C 12300
The length of data type String is
too large.
The number of characters in String data type
is too large. Update the software if the error
still exists after modifying the program, re-
compiling and re-downloading the program.
300D 12301
Illegal addressing method for
variables
Update the software if the error still exists after
re-compiling and re-downloading the program
and repowering the product.
300E 12302
Improper priority setting of the
task
Set a proper task priority and cycle time for
the task
300F 12303
Exception occurs during
accessing the controller's memory
Check whether any index is out of bounds of
the array in the program. The pointer is used
by not assigning it a value or is used by
assigning it an incorrect value. Contact local
technicians if the problem still exists after re-
downloading the program.
3020 12320
The checksum of the downloaded
Motion configuration is illegal.
Update the software
if the error still exists after
re-compiling and re-downloading the program
and repowering the product.
3021 12321
The checksum of the downloaded
extension configuration is illegal.
3022 12322
The checksum of the downloaded
program is illegal.
3023 12323
The checksum of the downloaded
task data is illegal.
3024 12324
The checksum of the downloaded
CANopen data is illegal.
3025 12325
The checksum of the downloaded
hardware configuration is illegal.
