Doosan H2017 - Page 207

207
No.
Item
Description
6
Move – Button
If the button is held down, the selected axis is moved in the -
direction in accordance with the increment location.
7
Move – Button
If the button is held down, the selected axis is moved in the +
direction in accordance with the increment location.
8
Force Monitoring
Displays the occurring external force based on the selected
coordinate system.
9
TCP Setting:
Sets TTCP.
10
Tool Weight Indicator
Sets the tool Weight.
11
Change Jog+ location
Changes the Jog+ location to the top or bottom of the
screen.
