Chapter 10
| Access Control Lists
IPv4 ACLs
– 329 –
Command Usage
◆
All new rules are appended to the end of the list.
◆
Address bit masks are similar to a subnet mask, containing four integers from 0
to 255, each separated by a period. The binary mask uses 1 bits to indicate
“match” and 0 bits to indicate “ignore.” The bit mask is bitwise ANDed with the
specified source IP address, and then compared with the address for each IP
packet entering the port(s) to which this ACL has been assigned.
◆
The control-code bitmask is a decimal number (representing an equivalent bit
mask) that is applied to the control code. Enter a decimal number, where the
equivalent binary bit “1” means to match a bit and “0” means to ignore a bit.
The following bits may be specified:
■
1 (fin) – Finish
■
2 (syn) – Synchronize
■
4 (rst) – Reset
■
8 (psh) – Push
■
16 (ack) – Acknowledgement
■
32 (urg) – Urgent pointer
For example, use the code value and mask below to catch packets with the
following flags set:
■
SYN flag valid, use “control-code 2 2”
■
Both SYN and ACK valid, use “control-code 18 18”
■
SYN valid and ACK invalid, use “control-code 2 18”
◆
If an Extended IPv4 rule and MAC rule match the same packet, and these rules
specify a “permit” entry and “deny” entry, the “deny” action takes precedence.
Example
This example accepts any incoming packets if the source address is within subnet
10.7.1.x. For example, if the rule is matched; i.e., the rule (10.7.1.0 & 255.255.255.0)
equals the masked address (10.7.1.2 & 255.255.255.0), the packet passes through.
Console(config-ext-acl)#permit 10.7.1.1 255.255.255.0 any
Console(config-ext-acl)#
This allows TCP packets from class C addresses 192.168.1.0 to any destination
address when set for destination TCP port 80 (i.e., HTTP).
Console(config-ext-acl)#permit 192.168.1.0 255.255.255.0 any destination-port
80
Console(config-ext-acl)#
