Chapter 9

| General Security Measures

Port-based Traffic Segmentation

– 323 –

show

traffic-segmentation

This command displays the configured traffic segments.

Command Mode

Privileged Exec

Example

Console#show traffic-segmentation

Traffic segmentation Status : Disabled

Uplink-to-Uplink Mode : Forwarding

Traffic segmentation Status : Disabled

Uplink-to-Uplink Mode : Forwarding

Session Uplink Ports Downlink Ports

--------- ------------------------------ -----------------------------

1 Ethernet 1/1 Ethernet 1/2

Ethernet 1/3

Ethernet 1/4

Console#
