Edge-Core ECS2100-28T Reference Guide

Chapter 4 | System Management Commands
Frame Size
– 99 –
Console#
show watchdog This command shows if watchdog debugging is enabled.
Command Mode
Privileged Exec
Example
Console#show watchdog
Software Watchdog Information
Status : Enabled
AutoReload : Enabled
Console#
Frame Size
This section describes commands used to configure the Ethernet frame size on the
switch.
Table 14: show version – display description
Parameter Description
Serial Number The serial number of the switch.
Hardware Version Hardware version of the main board.
Number of Ports Number of built-in ports.
Main Power Status Displays the status of the internal power supply.
Role Shows that this switch is operating as Master or Slave.
Loader Version Version number of loader code.
Linux Kernel Version Version number of Linux kernel.
Operation Code Version Version number of runtime code.
Table 15: Frame Size Commands
Command Function Mode
jumbo frame Enables support for jumbo frames GC

Edge-Core ECS2100-28T Specifications

General

Model	ECS2100-28T
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
MAC Address Table Size	16K
Jumbo Frame Support	9KB
VLANs	4K
Weight	3.5 kg
Storage Humidity	5% to 95% (non-condensing)
Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 1G SFP
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440 x 200 x 44 mm
Operating Temperature	0 to 50 °C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Management	SNMP
