Chapter 22

| Quality of Service Commands

– 543 –

show policy-map

interface

This command displays the service policy assigned to the specified interface.

Syntax

show policy-map interface

[interface

input

]

interface

unit/port

unit - Unit identifier. (Range: 1)

port - Port number. (Range: 1-10/28)

Command Mode

Privileged Exec

Example

Console#show policy-map interface 1/5 input

Service-policy rd-policy

Console#show policy-map interface

Interface ethernet 1/2

service-policy input policy-map

Interface ethernet 1/3

service-policy input policy-map

Interface ethernet 1/4

service-policy input policy-map

Interface ethernet 1/5

service-policy input policy-map

Console#
