Edge-Core ECS2100-28T Reference Guide

Chapter 9 | General Security Measures
Network Access (MAC Address Authentication)
– 274 –
clear network-access Use this command to clear entries from the secure MAC addresses table.
Syntax
clear network-access mac-address-table [ static | dynamic ]
[
address mac-address] [ interface interface]
static - Specifies static address entries.
dynamic - Specifies dynamic address entries.
mac-address - Specifies a MAC address entry. (Format: xx-xx-xx-xx-xx-xx)
interface - Specifies a port interface.
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-10/28)
Default Setting
None
Command Mode
Privileged Exec
Example
Console#clear network-access mac-address-table interface ethernet 1/1
Console#
show network-access Use this command to display the MAC authentication settings for port interfaces.
Syntax
show network-access [ interface interface]
interface - Specifies a port interface.
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-10/28)
Default Setting
Displays the settings for all interfaces.
Command Mode
Privileged Exec

Edge-Core ECS2100-28T Specifications

General

Model	ECS2100-28T
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
MAC Address Table Size	16K
Jumbo Frame Support	9KB
VLANs	4K
Weight	3.5 kg
Storage Humidity	5% to 95% (non-condensing)
Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 1G SFP
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440 x 200 x 44 mm
Operating Temperature	0 to 50 °C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Management	SNMP
