Chapter 11
| Interface Commands
Transceiver Threshold Configuration
– 372 –
â—†
Trap messages enabled by the transceiver-monitor command are sent to any
management station configured by the snmp-server host command.
Example
The following example sets alarm thresholds for the transceiver voltage at port 1.
Console(config)interface ethernet 1/1
Console(config-if)#transceiver-threshold voltage low-alarm 4
Console(config-if)#transceiver-threshold voltage high-alarm 2
Console#
show interfaces
transceiver
This command displays identifying information for the specified transceiver,
including connector type and vendor-related parameters, as well as the
temperature, voltage, bias current, transmit power, and receive power.
Syntax
show interfaces transceiver
[interface]
interface
ethernet
unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 9-10/25-28)
Default Setting
Shows all SFP interfaces.
Command Mode
Privileged Exec
Command Usage
The switch can display diagnostic information for SFP modules which support the
SFF-8472 Specification for Diagnostic Monitoring Interface for Optical Transceivers.
This information allows administrators to remotely diagnose problems with optical
devices. This feature, referred to as Digital Diagnostic Monitoring (DDM) in the
command display, provides information on transceiver parameters including
temperature, supply voltage, laser bias current, laser power, and received optical
power, and related alarm thresholds.
Example
Console#show interfaces transceiver ethernet 1/28
Information of Eth 1/49
Connector Type : LC
Fiber Type : [0x00]
Eth Compliance Codes : 1000BASE-ZX
Baud Rate : 1300 MBd
Vendor OUI : 00-00-5F
Vendor Name : SumitomoElectric
Vendor PN : SCP6G94-FN-BWH
