Edge-Core ECS2100-28T Reference Guide

Chapter 8 | Authentication Commands
Secure Shell
– 237 –
Command Mode
Global Configuration
Command Usage
◆ The SSH server supports up to eight client sessions. The maximum number of
client sessions includes both current Telnet sessions and SSH sessions.
◆ The SSH server uses DSA or RSA for key exchange when the client first
establishes a connection with the switch, and then negotiates with the client to
select either DES (56-bit) or 3DES (168-bit) for data encryption.
◆ You must generate DSA and RSA host keys before enabling the SSH server.
Example
Console#ip ssh crypto host-key generate dsa
Console#configure
Console(config)#ip ssh server
Console(config)#
Related Commands
ip ssh crypto host-key generate (239)
show ssh (242)
ip ssh server-key size This command sets the SSH server key size. Use the no form to restore the default
setting.
Syntax
ip ssh server-key size key-size
no ip ssh server-key size
key-size – The size of server key. (Range: 512-896 bits)
Default Setting
768 bits
Command Mode
Global Configuration
Command Usage
The server key is a private key that is never shared outside the switch.
The host key is shared with the SSH client, and is fixed at 1024 bits.
Example
Console(config)#ip ssh server-key size 512
Console(config)#

Edge-Core ECS2100-28T Specifications

General

Model	ECS2100-28T
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
MAC Address Table Size	16K
Jumbo Frame Support	9KB
VLANs	4K
Weight	3.5 kg
Storage Humidity	5% to 95% (non-condensing)
Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 1G SFP
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440 x 200 x 44 mm
Operating Temperature	0 to 50 °C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Management	SNMP
