Chapter 4

| System Management Commands

Switch Clustering

– 158 –

show cluster

candidates

This command shows the discovered Candidate switches in the network.

Command Mode

Privileged Exec

Example

Console#show cluster candidates

Cluster Candidates:

Role MAC Address Description

--------------- ----------------- ----------------------------------------

Candidate join 00-E0-0C-00-00-FE ECS2100-10T

Candidate 00-12-CF-0B-47-A0 ECS2100-10T

Console#
