Chapter 12
| Link Aggregation Commands
Trunk Status Display Commands
– 391 –
Console#show lacp 1 neighbors
Port Channel : 1
------------------------------------------------------------
Member Port : Eth 1/24
Partner Admin System ID : 32768, 00-00-00-00-00-00
Partner Oper System ID : 32768, FC-0A-81-B7-C7-E0
Partner Admin Port ID : 32768, 24
Partner Oper Port ID : 32768, 24
Partner Admin Key : 0
Partner Oper Key : 4
Partner Admin State : Defaulted, Distributing, Collecting,
Synchronization, Long Timeout, Passive LACP
Partner Oper State : Distributing, Collecting, Synchronization,
Aggregatable, Long Timeout, Actvie LACP
.
.
.
Console#show lacp sysid
Port Channel System Priority System MAC Address
-------------------------------------------------------------------------
1 32768 00-30-F1-8F-2C-A7
2 32768 00-30-F1-8F-2C-A7
3 32768 00-30-F1-8F-2C-A7
Admin State,
Oper State
(continued)
â—†
Aggregation – The system considers this link to be aggregatable; i.e., a
potential candidate for aggregation.
â—†
Long timeout – Periodic transmission of LACPDUs uses a slow transmission
rate.
â—†
LACP-Activity – Activity control value with regard to this link.
(0:Passive;1:Active)
Table 75: show lacp neighbors - display description
Field Description
Partner Admin
System ID
LAG partner’s system ID assigned by the user.
Partner Oper
System ID
LAG partner’s system ID assigned by the LACP protocol.
Partner Admin
Port Number
Current administrative value of the port number for the protocol Partner.
Partner Oper
Port ID
Operational port number assigned to this aggregation port by the port’s
protocol partner.
Port Admin Priority Current administrative value of the port priority for the protocol partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See preceding table.)
Oper State Operational values of the partner’s state parameters. (See preceding table.)
Table 74: show lacp internal - display description (Continued)
Field Description
