– 545 –
23
Multicast Filtering Commands
This switch uses IGMP (Internet Group Management Protocol) to check for any
attached hosts that want to receive a specific multicast service. It identifies the
ports containing hosts requesting a service and sends data out to those ports only.
It then propagates the service request up to any neighboring multicast switch/
router to ensure that it will continue to receive the multicast service.
IGMP Snooping
This section describes commands used to configure IGMP snooping on the switch.
Table 112: Multicast Filtering Commands
Command Group Function
IGMP Snooping Configures multicast groups via IGMP snooping or static assignment,
sets the IGMP version, enables proxy reporting, displays current
snooping settings, and displays the multicast service and group
members
Static Multicast Routing Configures static multicast router ports which forward all inbound
multicast traffic to the attached VLANs
IGMP Filtering and
Throttling
Configures IGMP filtering and throttling
MLD Snooping Configures multicast snooping for IPv6
MLD Filtering and
Throttling
Configures MLD filtering and throttling for IPv6.
Table 113: IGMP Snooping Commands
Command Function Mode
ip igmp snooping Enables IGMP snooping GC
ip igmp snooping priority Assigns a priority to all multicast traffic GC
ip igmp snooping
proxy-reporting
Enables IGMP Snooping with Proxy Reporting GC
ip igmp snooping querier Allows this device to act as the querier for IGMP snooping GC
ip igmp snooping router-
alert-option-check
Discards any IGMPv2/v3 packets that do not include the
Router Alert option
GC
ip igmp snooping
router-port-expire-time
Configures the querier timeout GC
ip igmp snooping tcn-flood Floods multicast traffic when a Spanning Tree topology
change occurs
GC
