Edge-Core ECS2100-28T Reference Guide

Chapter 23 | Multicast Filtering Commands
MLD Snooping
– 586 –
Command Usage
◆ When a new upstream interface (that is, uplink port) starts up, the switch sends
unsolicited reports for all currently learned multicast channels out through the
new upstream interface.
◆ This command only applies when proxy reporting is enabled (see page 581).
Example
Console(config)#ipv6 mld snooping unsolicited-report-interval 5
Console(config)#
ipv6 mld snooping
version
This command configures the MLD snooping version. Use the no form to restore
the default.
Syntax
ipv6 mld snooping version { 1 | 2 }
1 - MLD version 1.
2 - MLD version 2.
Default Setting
Version 2
Command Mode
Global Configuration
Example
Console(config)#ipv6 mld snooping version 1
Console(config)#
ipv6 mld snooping
vlan immediate-leave
This command immediately deletes a member port of an IPv6 multicast service
when a leave packet is received at that port and immediate-leave is enabled for the
parent VLAN. Use the
no form to restore the default.
Syntax
[
no ] ipv6 mld snooping vlan vlan-id immediate-leave
vlan-id - A VLAN identification number. (Range: 1-4094)
Default Setting
Disabled
Command Mode
Global Configuration

Edge-Core ECS2100-28T Specifications

General

Model	ECS2100-28T
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
MAC Address Table Size	16K
Jumbo Frame Support	9KB
VLANs	4K
Weight	3.5 kg
Storage Humidity	5% to 95% (non-condensing)
Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 1G SFP
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440 x 200 x 44 mm
Operating Temperature	0 to 50 °C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Management	SNMP
