Chapter 11
| Interface Commands
Transceiver Threshold Configuration
– 373 –
Vendor Rev : Z
Vendor SN : SE08T712Z00006
Date Code : 10-09-14
DDM Info
Temperature : 35.64 degree C
Vcc : 3.25 V
Bias Current : 12.13 mA
TX Power : 2.36 dBm
RX Power : -24.20 dBm
DDM Thresholds
Low Alarm Low Warning High Warning High Alarm
----------- ------------ ------------ ------------ ------------
Temperature(Celsius) -45.00 -40.00 85.00 90.00
Voltage(Volts) 2.90 3.00 3.60 3.70
Current(mA) 1.00 3.00 50.00 60.00
TxPower(dBm) -11.50 -10.50 -2.00 -1.00
RxPower(dBm) -23.98 -23.01 -1.00 0.00
Console#
show interfaces
transceiver-threshold
This command Displays the alarm/warning thresholds for temperature,
voltage, bias current, transmit power, and receive power.
Syntax
Syntax
show interfaces transceiver-threshold
[interface]
interface
ethernet
unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 9-10/25-28)
Default Setting
Shows all SFP interfaces.
Command Mode
Privileged Exec
Command Usage
â—†
The switch can display diagnostic information for SFP modules which support
the SFF-8472 Specification for Diagnostic Monitoring Interface for Optical
Transceivers. This information allows administrators to remotely diagnose
problems with optical devices. This feature, referred to as Digital Diagnostic
Monitoring (DDM) in the command display, provides information on
transceiver parameters including temperature, supply voltage, laser bias
current, laser power, received optical power, and related alarm thresholds.
â—†
The DDM thresholds displayed by this command only apply to ports which
have a DDM-compliant transceiver inserted.
Example
Console#show interfaces transceiver-threshold ethernet 1/25
Information of Eth 1/25
