Chapter 5
| SNMP Commands
SNMPv3 Commands
– 211 –
Command Mode
Global Configuration
Command Usage
◆ A group sets the access policy for the assigned users.
◆ When authentication is selected, the MD5 or SHA algorithm is used as specified
in the snmp-server user command.
◆ When privacy is selected, the DES 56-bit algorithm is used for data encryption.
◆ For additional information on the notification messages supported by this
switch, see the Web Management Guide. Also, note that the authentication, link-
up and link-down messages are legacy traps and must therefore be enabled in
conjunction with the snmp-server enable traps command.
Example
Console(config)#snmp-server group r&d v3 auth write daily
Console(config)#
snmp-server user This command adds a user to an SNMP group, restricting the user to a specific
SNMP Read, Write, or Notify View. Use the no form to remove a user from an SNMP
group.
Syntax
snmp-server user username groupname
{v1 | v2c | v3 [encrypted] [auth {md5 | sha} auth-password
[priv des56 priv-password]]
snmp-server user username groupname remote ip-address
{v3 [encrypted] [auth {md5 | sha} auth-password
[priv des56 priv-password]]
no snmp-server user username {v1 | v2c | v3 | remote}
username - Name of user connecting to the SNMP agent.
(Range: 1-32 characters)
groupname - Name of an SNMP group to which the user is assigned.
(Range: 1-32 characters)
remote - Specifies an SNMP engine on a remote device.
ip-address - IPv4 address of the remote device.
v1 | v2c | v3 - Use SNMP version 1, 2c or 3.
encrypted - Accepts the password as encrypted input.
auth - Uses SNMPv3 with authentication.
2. Maps to the defaultview.
