Chapter 21
| VLAN Commands
Configuring IEEE 802.1Q Tunneling
– 596 –
Step 2. Configure Switch C.
1. Create VLAN 100, 200 and 300.
Console(config)#vlan database
Console(config-vlan)#vlan 100,200,300 media ethernet state active
2. Configure port 1 and port 2 as tagged members of VLAN 100, 200 and 300.
Console(config)#interface ethernet 1/1,2
Console(config-if)#switchport allowed vlan add 100,200,300 tagged
switchport
dot1q-tunnel tpid
This command sets the Tag Protocol Identifier (TPID) value of a tunnel port. Use the
no form to restore the default setting.
Syntax
switchport dot1q-tunnel tpid tpid
no switchport dot1q-tunnel tpid
tpid – Sets the ethertype value for 802.1Q encapsulation. This identifier is
used to select a nonstandard 2-byte ethertype to identify 802.1Q tagged
frames. The standard ethertype value is 0x8100. (Range: 0800-FFFF
hexadecimal)
Default Setting
0x8100
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
â—† Use the switchport dot1q-tunnel tpid command to set a custom 802.1Q
ethertype value on the selected interface. This feature allows the switch to
interoperate with third-party switches that do not use the standard 0x8100
ethertype to identify 802.1Q-tagged frames. For example, 0x1234 is set as the
custom 802.1Q ethertype on a trunk port, incoming frames containing that
ethertype are assigned to the VLAN contained in the tag following the
ethertype field, as they would be with a standard 802.1Q trunk. Frames arriving
on the port containing any other ethertype are looked upon as untagged
frames, and assigned to the native VLAN of that port.
â—† The specified ethertype only applies to ports configured in Uplink mode using
the switchport dot1q-tunnel mode command. If the port is in normal mode (i.e,
unspecified), the TPID is always 8100. If the port is in Access mode, received
packets are processes as untagged packets.
Example
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel tpid 9100
Console(config-if)#
