Chapter 21 | VLAN Commands
Configuring IEEE 802.1Q Tunneling
– 597 –
Related Commands
show interfaces switchport (429)
show dot1q-tunnel This command displays information about QinQ tunnel ports.
Syntax
show dot1q-tunnel [interface interface [service svid] | service [svid]]
interface
ethernet unit/port
unit - Unit identifier. (Range: 1-8)
port - Port number. (Range: 1-28/52)
port-channel channel-id (Range: 1-16)
svid - VLAN ID for the outer VLAN tag (SPVID). (Range: 1-4094)
Command Mode
Privileged Exec
Example
Console(config)#dot1q-tunnel system-tunnel-control
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel mode access
Console(config-if)#interface ethernet 1/2
Console(config-if)#switchport dot1q-tunnel mode uplink
Console(config-if)#end
Console#show dot1q-tunnel
802.1Q Tunnel Status : Enabled
Port Mode TPID (hex)
-------- ------ ----------
Eth 1/ 1 Access 8100
Eth 1/ 2 Uplink 8100
Eth 1/ 3 Normal 8100
.
.
.
Console#show dot1q-tunnel interface ethernet 1/5
802.1Q Tunnel Service Subscriptions
Port Match C-VID S-VID
-------- ----------- -----
Eth 1/ 5 1 100
Console#show dot1q-tunnel service 100
802.1Q Tunnel Service Subscriptions
Port Match C-VID S-VID
-------- ----------- -----
Eth 1/ 5 1 100
Eth 1/ 6 1 100
Console#
