Chapter 2
| Using the Web Interface
Navigating the Web Browser Interface
– 67 –
Show Rule Shows the time specified by a rule 321
Configure ACL 324
Show TCAM Shows utilization parameters for TCAM 323
Add Adds an ACL based on IP or MAC address filtering 324
Show Shows the name and type of configured ACLs 324
Add Rule Configures packet filtering based on IP or MAC addresses and other
packet attributes
324
Show Rule Shows the rules specified for an ACL 324
Configure Interface Binds a port to the specified ACL and time range
Configure Binds a port to the specified ACL and time range 337
Add Mirror MIrrors matching traffic to the specified port 338
Show Mirror Shows ACLs mirrored to specified port 338
Show Hardware Counters Shows statistics for ACL hardware counters 340
ARP Inspection 341
Configure General Enables inspection globally, configures validation of additional address
components, and sets the log rate for packet inspection
342
Configure VLAN Enables ARP inspection on specified VLANs 344
Configure Interface Sets the trust mode for ports, and sets the rate
limit for packet inspection
345
Show Information 347
Show Statistics Displays statistics on the inspection process 347
Show Log Shows the inspection log list 348
IP Filter 349
Add Sets IP addresses of clients allowed management access via the web,
SNMP, and Telnet
349
Show Shows the addresses to be allowed management access 349
Port Security Configures per port security, including status, response for security
breach, and maximum allowed MAC addresses
351
Port Authentication IEEE 802.1X 353
Configure Global Enables authentication and EAPOL pass-through 355
Configure Interface Sets authentication parameters for individual ports 356
Show Statistics Displays protocol statistics for the selected port 363
DoS Protection Protects against Denial-of-Service attacks 365
Table 4: Switch Main Menu (Continued)
Menu Description Page
