115 |
ETAS ES800 System | User Guide
13.3.3 Position of the Modules
13.3.4 Sequence for Stacking
- The modules must be arranged in ascending order from bottom to top
according to their categories.
- Modules with an identical category can be positioned in any order.
- If there are no modules of a category, the module of the next following cate-
gory is installed.
13.3.5 Examples
ES820.1 and ES830.1 Modules
The ES820.1 and ES830.1 modules are modules of category 2:
- Modules of category 2 must be positioned above modules of category 1 and
below modules of category 3A.
- Several modules of category 2 can be arranged in random order.
ES882.x, ES886.x, ES891.x and ES892.x Modules
The ES882.x, ES886.x, ES891.x, and ES892.x modules are modules of category 3A.
It must be positioned above modules of category 0, 1 and 2 as well as below mod
-
ules of category 3B and 4.
Position in the stack Category Module (example)
5 (top) 4 Reserved
4 3B Reserved
3 3A ES882.x, ES886.x, ES891.x,
ES892.x
2 2 ES820.1, ES830.1
1 1 Reserved
0 (bottom) 0 ES801.1, ES801.1-S
