ETAS ES800 System | User Guide
17.11 ES800 Memory Module Type 1
The measured data of the Drive Recorder ES820.1 is recorded on the ES800 mem-
ory module type 1. It is located in a slot on the front of the ES820.1 module and is
secured in place with push and twist closures.
Fig. 17-37 Memory module type 1
The memory module can be removed from the Drive Recorder in order to transfer
the data to another disk-space (e.g., the company network). An ES800 docking
station type 1 is required in order to read the data on a PC.
Fig. 17-38 Memory module, front view
NOTE
The memory module is not included in the scope of supply of the Drive Recorder.
Order name Short name Order number
Memory Module (Type 1) for ES800 - 500 GB AC800MM1-500 F 00K 110 255
Memory Module (Type 1) for ES800 - 1 TB AC800MM1-1T F 00K 110 256
