135 | Applications
ETAS ES800 System | User Guide
14.6 Dual Mode ETKs on ES89x Modules
At the FETK/GE interfaces of the ES89x modules, Dual Mode ETKs (e.g. ETK-S20.1,
ETK-S21.1) can be operated in FETK mode.
Dual Mode ETKs can use the same A2L file in ETK mode and in FETK mode; changes
are not required.
14.6.1 Cabling
Connecting a Dual Mode ETK requires a CBAE360 adapter cable which is con
-
nected to the ES89x and to the ETK CBM150 connecting cable.
14.6.2 Checking the Dual Mode ETK
If a Dual Mode ETK is connected to the ES89x, the ES89x module automatically
checks whether the connected ETK is a Dual Mode ETK. If a Dual Mode ETK was
detected, a check is performed to ascertain whether it is prepared for operation at
the FETK/GE interface. This state of the ETK is indicated by the LED at the FETK / GE
interface:
NOTE
An overview of the system requirements for the operating mode FETK Mode is
located in the user guides of the ETKs.
FETK / GE LED Description
Off The connected ETK is not a Dual Mode ETK. Operating the ETK at
the ES89x module is not possible.
Red If the connected ETK is a Dual Mode ETK, the ETK is not prepared
for operation at the 89x module. It is necessary to update the
ETK with HSP.
Yellow The connected ETK is a Dual Mode ETK and prepared for opera-
tion at the 89x module. It is not necessary to update the ETK with
HSP.
