55 | ES830.1 Rapid Prototyping Module
ETAS ES800 System | User Guide
6.6 Switching the Rapid Prototyping Module On and Off
6.6.1 Switching On
If the Rapid Prototyping Module ES830.1 is in the "Off" state and the "Power" key on
the module or an external "Remote power" key on the "I/O" connection is pressed
once, the module switches to the "On" state. This starts the installed operating
system.
6.6.2 Power Off
Switching Off (Shutting Down)
If the Rapid Prototyping Module ES830.1 is in the "On" state and the "Power" key on
the module, an external "Remote power" key on the "I/O" connection is pressed
twice within 5 seconds, the module or the ES800 module stack is switched off.
If wake-up conditions for the ES830.1 module or for a module within the stack are
configured and satisfied, the system immediately restarts.
Switching Off by Disconnecting the Module from the Supply Volt-
age
Error Handling
If errors occur during the switch-off process, this is indicated by the ERR LED and
the switch-off process is continued.
6.6.3 Remote Function of the "Power" Button
If necessary, the function of the "Power" button on the ES830.1 module can be
assumed by an external "Remote Power" button. To use this function, connect an
external button to the "IN_POWER_BUTTON" pin at the "I/O" connection (see
chapter
16.10.11 on page 176).
NOTE
Prototyping model can be stopped!
Always switch off the ES830.1 Rapid Prototyping Module with the "Power" key or
the "Remote Power" key.
This ensures that the processes carried out by the system and any active mod-
els are stopped correctly.
NOTE
The ES830.1 Rapid Prototyping Module must not be disconnected from the
power supply while a model is active. This ensures that any active models are
stopped correctly.
