ETAS ES800 - Data Transfer; Data Transfer Options; Media for Data Transfer

47 | ES820.1 Drive Recorder
ETAS ES800 System | User Guide
5.6 Data Transfer
5.6.1 Data Transfer Options
Manual Data Transfer (Direct Access)
The exchange of configuration data (configuration settings) and the recorded
data is triggered by the user in the "Drive Recorder Configurator" program. The
data can be transferred via cable or wireless (see chapter
5.6.2 on page 47).
Automatic Data Transfer (Remote Access)
If "Automatic Data Transfer" is selected in the configuration data of the ES820.1,
the module checks during the upload of the recorded data to the PC or server
whether a new configuration assigned to the module is available on the PC on
server. If a new configuration exists, ES820.1 uses this configuration for the next
data recording. The data can be transferred via cable or wireless (see chapter
5.6.2 on page 47). The remote access allows operating the Drive Recorder auto-
matically without user interaction.
5.6.2 Media for Data Transfer
Dependent on the add-on modules used, several options are available for the
exchange of configuration data and recorded data:
- Cable-based data transfer
• LAN
Connection of the ES820.1 at the "HOST" interface to the PC via an Ether-
net cable
• USB
Using a USB memory device on the "USB" port of the ES820.1
- Wireless data transfer
The ES820.1 Drive Recorder can be connected via an Ethernet or WLAN
adapter with an external mobile or WLAN router to an SFTP server on the
Internet:
• Using a USB Ethernet adapter on the "USB" port, or
• Using a USB WLAN adapter at the "USB" port that is protected via the
WPA2 security standard
NOTE
ETAS does not recommend a special router. The choice is the responsibility of
the customer.
NOTE
ETAS recommends a security check of the router in combination with the
ES820.1 Drive Recorder and the additional modules used. A corresponding ser-
vice (e.g. penetration test) can be booked at ETAS/ ESCRYPT. Please contact
your ETAS contact partner.
