17.7.2 FlexRay Terminating Resistor
Fig. 17-27 Terminating resistor CBFX131.1-0
Order name Short name Order
number
FlexRay Termination Resistor 100 Ohm, 2xD-
SUB (9fc-9mc)
CBFX131.1-0 F 00K 104 689
5
4
3
2
1
6
7
8
9
5
4
3
2
1
9
8
7
6
100R0 / 1%
