ETAS ES800 System | User Guide
17.8.5 Cable K107
Fig. 17-32 Cable K107
17.8.6 CAN Terminating Resistor
Fig. 17-33 Terminating resistor CBCX131.1-0
Side A Side B
Order name Short name Order number
CAN Interface Y-Cable, Lemo 1B FGC Lemo 0S
PCA Lemo 0S FFA (8mc,- 2fc+2mc) , 2 m
K107 F 00K 001 272
Order name Short name Order number
CAN 120 Ohm Terminating Resistor,
2xDSUB (9fc+9mc)
CBCX131.1-0 F 00K 103 786
5
4
3
2
1
6
7
8
9
5
4
3
2
1
9
8
7
6
120 Ohm
