ETAS ES800 System | User Guide
16.9.6 FETK/Gigabit Ethernet Interface (FETK/GE)
Applications with ETAS Modules from other Series
If the FETK/GE interface is used as a Gigabit Ethernet connection to connect to
ETAS modules from other series, please note the following:
The synchronization of the ETAS modules from other series, which are connected
via the "GE-HOST" Gigabit HOST interface of an ES600.2 module to the "GE" inter
-
face of an ES800 module, is supported.
The "Wake-Up" and "Sleep" functions of the ES800 modules that are performed
using ETAS modules from other series, which are connected to the "FE" interface
or via the "GE-HOST" Gigabit HOST interface of an ES600.2 module to the "GE"
interface of an ES800 module, are supported.
NOTE
The technical data for the FETK / Gigabit Ethernet interfaces (FETK / GE) of the
module is identical.
NOTE
The FETK/GE interface can be used for connecting an ETK (Dual Mode), an FETK
or as a Gigabit Ethernet connection.
Connection type Downstream
Number 2 (FETK1 / GE, FETK2 / GE)
Connection Duplex mode;
IEEE 802.3 - 1000BASE-T,
IEEE 802.2 - 100BASE-TX
Protocol TCP/IP
Support Gigabit Ethernet or FETK or ETK in FETK
mode
Synchronization IEEE1588-2008
Synchronization resolution 1 s
Output current for each connection max. 0.5 A (for power supply to connected
ETAS modules)
Connectible ETAS modules ES882.x, ES886.x, ES891.x, ES892.x, ETK
(Dual Mode), FETK
Electrical isolation Ethernet connections electrically isolated
from the module, power supply connec-
tions not electrically isolated from the
module
