16.9.5 Gigabit Ethernet Interface (GE)
Applications with ETAS Modules from other Series
If the GE interface is used to connect to ETAS modules from other series, please
note the following:
The synchronization of the ETAS modules from other series, which are connected
via the "GE-HOST" Gigabit HOST interface of an ES600.2 module to the "GE" inter
-
face of an ES800 module, is supported.
The "Wake-Up" and "Sleep" functions of the ES800 modules that are performed
using ETAS modules from other series, which are connected to the "FE" interface
or via the "GE-HOST" Gigabit HOST interface of an ES600.2 module to the "GE"
interface of an ES800 module, are supported.
NOTE
The GE interface of the ES820.1 Drive Recorder can be used to connect addi-
tional ETAS modules.
NOTE
The GE interface of the ES830.1 Rapid Prototyping Module can be used to con-
nect additional ETAS modules.
Connection type Downstream
Number 1 (GE)
Connection Duplex mode;
IEEE 802.3 - 1000BASE-T,
IEEE 802.2 - 100BASE-TX
Protocol TCP/IP
Support Gigabit Ethernet
Ethernet Monitoring (ES886.x):
Hardware based filtering
VLAN filter
Synchronization IEEE1588-2008
Synchronization resolution 1 s
Output current for each connection max. 0.5 A (for power supply to connected
ETAS modules)
Connectible ETAS modules ES882.x, ES886.x, ES891.x, ES892.x,
ES600.2, ES162.1
Electrical isolation Ethernet connections electrically isolated
from the module, power supply connec-
tions not electrically isolated from the
module
