Pin Assignments of the Cable at the CAN1/CAN2 interface

The signals of the CAN1/CAN2 interface are assigned to the DSUB socket-plug

combinations of the cable CBCFI100 as follows:

Lemo

[side A]

DSUB,

color: gray

[side B, side C]

Pin Signal Pin Signal

1 - 1 -

2 CAN1_LOW 2 CAN1_LOW

3 CAN1_GND_1 3 CAN1_GND_1

4 CAN2_HIGH 4 -

5 CAN2_GND 5 -

6 CAN1_GND_2 6 CAN1_GND_2

7 CAN1_HIGH 7 CAN1_HIGH

8 CAN2_LOW 8 -

9 -

DSUB,

color: black

[side D, side E]

Pin Signal

1 -

2 CAN2_LOW

3 CAN2_GND

4 -

5 -

6 -

7 CAN2_HIGH

8 -

9 -
