ETAS ES800 System | User Guide
Pin Assignments of the Cable at the CAN3/CAN4 interface
The signals of the CAN3/CAN4 interface are assigned to the DSUB socket-plug
combinations of the cable CBCFI100 as follows:
Lemo
[side A]
DSUB,
color: gray
[side B, side C]
Pin Signal Pin Signal
1 - 1 -
2 CAN3_LOW 2 CAN3_LOW
3 CAN3_GND_1 3 CAN3_GND_1
4 CAN4_HIGH 4 -
5 CAN4_GND 5 -
6 CAN3_GND_2 6 CAN3_GND_2
7 CAN3_HIGH 7 CAN3_HIGH
8 CAN4_LOW 8 -
9 -
DSUB,
color: black
[side D, side E]
Pin Signal
1 -
2 CAN4_LOW
3 CAN4_GND
4 -
5 -
6 -
7 CAN4_HIGH
8 -
9 -
