ETAS ES800 System | User Guide
16.9.4 Fast Ethernet Interface (FE)
Applications with ETAS Modules from other Series
If the FE interface is used to connect to ETAS modules from other series, please
note the following:
The synchronization of the ETAS modules from other series, which are connected
via the "GE-HOST" Gigabit HOST interface of an ES600.2 module to the "GE" inter
-
face of an ES800 module, is supported.
The "Wake-Up" and "Sleep" functions of the ES800 modules that are performed
using ETAS modules from other series, which are connected to the "FE" interface
or via the "GE-HOST" Gigabit HOST interface of an ES600.2 module to the "GE"
interface of an ES800 module, are supported.
Connection type Downstream
Number 1 (FE)
Connection Duplex mode;
IEEE 802.3 - 10BASE-T,
IEEE 802.2 - 100BASE-TX
Protocol TCP/IP
Support Fast Ethernet
Ethernet Monitoring (ES886.x):
Hardware based filtering
VLAN filter
Synchronization ETAS synchronization mechanism or
IEEE1588-2008
Synchronization resolution ETAS synchronization mechanism:
1 ms
IEEE1588-2008 synchronization:
1 s
Output current at connection max. 2 A (for power supply of connected
ETAS modules)
Connectible ETAS modules ES165.1, ES4xx, ES6xx, ES523.1, ES59x,
XETK
Electrical isolation Ethernet connections electrically isolated
from the module, power supply connec-
tions not electrically isolated from the
module
