ETAS ES800 System | User Guide
16.9.2 Power Supply of the ES800 Modules
ES820.1 Drive Recorder
Operating voltage range (max.) 6 V to 32 V DC
Operating voltage (typ.) 12 V DC
Current consumption Operation:
Max. 8 A at 6 V DC,
Max. 5 A at 12 V DC,
Max. 2 A at 32 V DC
Fast boot standby:
< 60 mA at 12 V DC, max. 120 mA
(without current consumption of con-
nected devices)
Low power standby:
< 10 mA at 12 V DC, max. 20 mA
(without current consumption of con
-
nected devices)
Energy management "On/Off" with start/stop of Ethernet traffic
"On" with start of a connected module
"On/Off", timer-based
"On/Off" via button on the front plate
"On/Off" via I/O interface
Protection Protection against reverse polarity, over-
load protection
Overvoltage category
(mains supply, IEC 60664-1)
II
