ETAS ES800 System | User Guide
ES830.1 Rapid Prototyping Module
ES882.x ECU and Bus Interface Module
ES886.x ECU and Bus Interface Module
Operating voltage range 6 V to 32 V DC
Operating voltage (typ.) 12 V DC
Current consumption Operation:
Max. 8 A at 6 V DC,
Max. 5 A at 12 V DC,
Max. 2 A at 32 V DC
Standby:
< 10 mA at 12 V DC, max. 20 mA
(without current consumption of con-
nected devices)
Energy management "On/Off" with start/stop of Ethernet traffic
"On" with start of a connected module
"On/Off" via button on the front plate
"On/Off" via I/O interface
Protection Protection against reverse polarity, over-
load protection
Overvoltage category
(mains supply, IEC 60664-1)
II
Operating voltage ES882.1: 6V to 32V DC
ES882.2: 7V to 29V DC
Operating voltage (typ.) 12 V DC
Current consumption, operation Max. 7 A at 6 V DC,
Max. 5 A at 12 V DC,
Max. 4 A at 32 V DC
Current consumption, standby Typ. 17 mA at 12 V DC
Max. 25 mA
Output current per "GE" connec-
tion
Nom. max. 0.5 A
Output current per "FE" connec-
tion
Nom. max. 2 A
Energy management On/Off with start/stop of Ethernet traffic
(On/Off upstream module)
Protection Protection against reverse polarity, overload
protection
Overvoltage category
(mains supply, IEC 60664-1)
II
Operating voltage ES886.1: 6V to 32V DC
ES886.2: 7V to 29V DC
Operating voltage (typ.) 12 V DC
Current consumption, operation Max. 7 A at 6 V DC,
Max. 5 A at 12 V DC,
Max. 4 A at 32 V DC
